Planed Cedar Pergola - Katepal Grey Roof - No Overhang

Delivered within 15-20 Working Days

Request a callback from our technical experts

SKU: EBP-CDRPERGOLA1.8x1.8KPALGRY
Length (Front to Back) :
Width (Front to Back)
£1,669.00
Price including VAT
- +

Key Facts:

  • 5" x 5" Posts
  • 4" x 2" Beams
  • Kit Form (Easy Install)
  • Full installation guide provided

Featuring a sophisticated grey shingle roof made from premium Katepal materials, this pergola seamlessly marries natural beauty with exceptional durability. Crafted from rough sawn cedar, it delivers superior weather resistance, enduring performance, and a striking design that elevates any outdoor setting.

Engineered for effortless assembly and minimal upkeep, this pergola is ideal for creating a snug lounge area, a chic dining space, or a sheltered retreat in your garden. Available in various sizes and customizable to suit your specific needs, the Rough Sawn Cedar Pergola – Katepal Grey Roof combines style with practicality, ensuring it remains a standout feature in your outdoor space for years to come.

Please Note: If you order a waterproof membrane as well, it will arrive cut to the size of your pergola roof.

Need further advice? Check out our new…

Pergola Buying Guide

Pergola Style Guide

Pergola Roofing Guide

A Guide to Our Materials

Product Details
SKU: EBP-CDRPERGOLA1.8x1.8KPALGRY
Weight: 0.0kg
Specification
Length 1.8m (6ft), 2.1m (7ft), 2.4m (8ft), 2.7m (9ft), 3.0m (10ft), 3.3m (11ft), 3.6m (12ft), 3.9m (13ft), 4.2m (14ft). Contact us for bespoke / custom Gazebo
Width 1.8m (6ft), 2.1m (7ft), 2.4m (8ft), 2.7m (9ft), 3.0m (10ft), 3.3m (11ft), 3.6m (12ft), 3.9m (13ft), 4.2m (14ft)
Total Height 270cm - 285cm
Post Height 2320mm
Post Size 145mm x 145mm
Corner Brackets 95mm x 45mm
Roofing Katepal Grey Shingle
Material & Timber
Planed British Cedar
Fixings All fixings included*
Frame Manual Instructions



Technical Drawing
Planed Cedar Pergola - Katepal Grey Roof - No Overhang drawing View Larger Version
FAQs
Product
What are Katepal Shingles made from?

All Katepal roofing shingles are made of SBS Bitumen and all have excellent performance properties, such as a high tolerance for bending and better tear resistance.

Do you make bespoke pergolas?

We absolutely do! Just like our gates and fencing, we can make completely bespoke pergolas. If you'd like a quote for your measurements, please contact our Sales team on 01409 231 763 or sales@ruby-group.co.uk.

Is your Katepal Green Shingle Apex Gazebo weatherproof?

If a weatherproof membrane is used, and adequately maintained with Osmo Oil, our pergolas are weatherproof.

What does 'with No Overhang' mean?

A Pergola with No Overhang does not have roofing that comes out past the front ring beam to create 'Overhang'.

What is the difference between an Apex Pergola and a 4 Pitch Apex Pergola?

An Apex roof pergola is a pergola that has a roof with two slopes that form an “A” shape, with the “apex” being the high point or peak where the slopes meet in the middle. Whereas, our 4 pitch pergola forms a 'cone' shape, with the 4 sides meeting in the middle.

Installation
Does the gazebo arrive fully assembled?

The Gazebo does not arrive fully assembled, however we have created in-depth manuals to guide you on assembly - so whether you're a keen DIY enthusiast or a professional fitter, you can construct our pergolas yourself. You can find these manuals on the specification table on each listing.

Are fixings included?

All the fixings needed for installation are included in the delivery of your pergola parts!

Aftercare and Maintenance
Can I paint my pergola?

You can! You can only use water-based paint on our pergolas, however, and you will need to ensure the pergola is as dry as possible before painting. We do recommend applying UV protection prior to painting also.

What maintenance is required?

We highly recommend treating your pergola at least every 6 months with Osmo Oil, to protect your gazebo against the elements and against decay. We also recommend checking your pergola every so often and removing any built-up dirt and grime.

How long does your Gazebos last?
Delivery
How much is shipping?

Delivery fees may vary depending on your order and location. To check the delivery fee for your purchase, simply proceed to the checkout where it will be calculated for you.

How long will it take to get my order?

The lead time varies depending on the product, and will stated below the pricing of the item for you.

What shipping courier do you use?

We use our own fleet of delivery drivers to ensure the best service! Our drivers are more than happy to leave your goods in a safe place! Your order will be fully trackable, with a 1-hour time slot provided! Our tracking app will allow you to see the progress of the driver throughout the day.

Terms and Conditions
Terms

Please Note: *The pergola comes without a waterproof roof membrane so will not be waterproof. If you would like to make it waterproof, you can simply apply a waterproof roof membrane, available here. Feet are not included in accessories but are an optional extra.

This product is specifically manufactured upon order placement and falls under our "Made-To-Measure" product range. We encourage you to review our Terms and Conditions (Section 2) before placing an order, as they detail guidance regarding orders, returns, and cancellations for "Made-To-Measure" product range.
